| High Power DPDT (Transfer) Switches | |
All Solid-State Construction Custom Makes
are Available (Consult Factory) |
|
|
Sales/Technical Contact Email: Sales@UMCC111.com |
|
|
||||
 |
Common Specifications |
RF Circuit / DPDT |
 |
|
|
|
Available Options | |||
|
> Specifications are subject to change
without notice > for Specifications-Sheet in PDF, click on the product model number > to see the actual response curves, click on "  " (subject to availability) |
||||
Model
No. |
Frequency (GHz) |
Insertion
Loss (dB) Max |
Isolation (dB) Min |
VSWR Max |
Rise/Fall
Time Max |
On/Off Time Max |
Power Handling, Max |
Supply Voltage |
Outline Drawing |
|
| cw/avg | peak | |||||||||
|
SR-AV0H-TS |
0.25 - 1.25 | 0.5 | 32 | 1.2:1 | 450 ns | 650 ns |
20W (Note 1) |
100W (Note 3) |
+5(-/+0.25)V / 270mA -15(-/+0.5)V / 80mA (Note 4) |
Fig.1 |
|
SR-5650-TS
|
0.65-5.65 | 1.0 | 38 |
1.45:1 | 250 ns | 350 ns |
5W (Note 1) |
50W (Note 3) |
+5(-/+0.25)V / 120mA -12(-/+0.5)V / 250mA (Note 4) |
Fig.1 |
|
1) Hot Switching 2) Cold Switching 3) 1μS Pulse Width Max 4) Dynamic Currents |
||||||||||
| All Models: | ||
 Impedance: |
50 Ω Nominal | |
|
Control Input Characteristic: |
TTL, One Unit Load (1.6mA Sink / 40μA Source), Floating-High | |
| Logic "0" ( 0 to +0.8V) ; Logic "1" (+2.2 to +5.0V) | ||
|
Connectors: |
||
| - RF Input / Output | SMA (female) | |
| - Supply | Solder Pins | |
| - Control | Solder Pins | |
Environmental Ratings: |
||
| Temperature: |
||
| - Operating | -55 degC to +95 degC | |
| - Storage | -60 degC to +110 degC | |
| Humidity: |
Mil-STD-202F, Method 103B Condition B | |
| Shock: |
Mil-STD-202F, Method 213B Condition B | |
| Vibration: |
Mil-STD-202F, Method 204D Condition B | |
| Altitude: |
Mil-STD-202F, Method 105C Condition B | |
| Temp. Cycle: |
Mil-STD-202F, Method 107D Condition B | |
Available Options: 1) units with combination of the following options may require some specification tradeoffs from the standard 2) Some options may not be available on all models |
|||
|
RF Connectors |
Control Impedance |
||
| B1) J1&J2 Ports with SMA(M) | D1) 50 Ω, Internally Terminated | ||
| B2) All Ports with SMA(M) | |||
| B3) COM(J0) Port with SMA(M) |
Control Function |
||
| F1) Inverse Logic | |||
|
|
|
|
|
